Back-LIT Panel

P30

ERVAN Backlit panel provides excellent visual comfort with micro prismatic diffuser and SDCM 3 color uniformity, tunable white function with circadian rhythms LEDs which is good HCL solution for applications such as schools, offices and supermarket..

Parameter Accessory Video Smart control

Size	Wattage	Lumen	Efficiency	CRI	CCT	SDCM	UGR
595x595x35mm	36W	4320LM	120lm/w	80	4000K	3	19
1195x295x35mm	36W	4320LM	120lm/w	80	4000K	3	19
1195x595x35mm	72W	8640LM	120lm/w	80	4000K	3	19
620x620x35mm	36W	4320LM	120lm/w	80	4000K	3	19

Name Description

Hook Suspending

Stainless steel material; For suspension using; 4pcs/set

Suspending Cable

Stainless steel material; For suspension using; 2pcs/set

Spring Bracket

Stainless steel material; For built-in ceiling using; 4pcs/set

Surface Mounted

Aluminium material; Used for the ceiling mounted; 1pc/set

Backlit panel factory ERVAN

Back-LIT Panel-P30

Structure Data

Input: AC220~240V 50/60Hz
Wiring: Loop in & loop out available
Function: 1~10V DIM | DALI
Flicker: Flicker free available
Driver: Power adjustable available
Material: Aluminum
Installation: Ceiling mounted; Suspension
Protection: IP20/IK06
CCT: Tunable white 2700-6500k available
